# 6GK5206-1BC00-2AF2 SCALANCE XF206-1, managed Layer 2 flat switch, 6x RJ45, 1x multimode ST/BFOC

SCALANCE XF206-1, managed Layer 2 flat switch, 6x RJ45, 1x multimode ST/BFOC

## Základní informace

| Parametr | Hodnota |
| --- | --- |
| Unit | pcs |
| Code 1 | SI_6GK5206-1BC00-2AF2 |
| Code 2 | 6GK5206-1BC00-2AF2 |
| Warranty | 12 |
| Warranty for companies | 12 |
| Brand | SIEMENS |

## Podrobný popis

SCALANCE XF206-1, flat, Managed IE switch, 6x 10/100 Mbit/s RJ45 ports, 1x 100 Mbit/s FO port, Error signaling contact with set pushbutton, redundant power supply, PROFINET IO device, network management, Redundancy Manager integrated, incl. electron. manual on CD-ROM, C-PLUG optional. SCALANCE XF206-1 managed, Layer 2 flat switch, 6x 10/100 Mbps RJ45, 1x 100 Mbps multimode ST/BFOC for use in control cabinet of SIMATIC ET 200S design. Suitable for numerous tasks: SCALANCE XF206-1 offers a wide variety of high-performance Ethernet switches in different variants from Gigabit switches to rugged switches for the requirements of process and discrete automation. The high-performance SCALANCE XF206-1 Gigabit switches are designed for demanding networks in industrial environments. Thanks to their high-performance hardware and advanced features, they benefit from a reliable and scalable network infrastructure for any application. You can solve numerous industrial applications easily and reliably.
